WANG Haipeng, LI Jianyong, ZHAO Chaoyue, LIU Yueming. Modeling and finite element simulation of temperature field in rail abrasive belt grinding[J]. Diamond & Abrasives Engineering, 2025, 45(3): 385-395. doi: 10.13394/j.cnki.jgszz.2024.0050
Citation: WANG Haipeng, LI Jianyong, ZHAO Chaoyue, LIU Yueming. Modeling and finite element simulation of temperature field in rail abrasive belt grinding[J]. Diamond & Abrasives Engineering, 2025, 45(3): 385-395. doi: 10.13394/j.cnki.jgszz.2024.0050
shu

Modeling and finite element simulation of temperature field in rail abrasive belt grinding

doi: 10.13394/j.cnki.jgszz.2024.0050
  • 1.

    School of Mechanical, Electronic and Control Engineering, Beijing Jiaotong University, Beijing, 100044, China

  • 2.

    China Energy Railway Equipment Co., Ltd., Beijing 100089, China

More Information
  • Received Date: 2024-03-16
  • Accepted Date: 2024-08-12
  • Rev Recd Date: 2024-08-02
    Abstract
  •   Objectives  Rail is an important component of rail transit, carrying train loads and guiding vehicle direction in service. Due to worn-outs and shocks during service, rails can cause various defects such as corrugation, spalling and squat, which seriously threaten the safety of train running, reduce the stability of train running and produce huge running noise. The use of sand belt grinding to remove the surface material of steel rails can remove surface defects and achieve the goal of extending the service life of steel rails. However, during the grinding process, a large amount of grinding heat will be generated in the grinding area between the sand belt and the rail, causing the temperature of the rail to rise. Due to differences in temperature distribution and cooling rates, residual stress will be generated on the surface of the rail, and martensitic burns may occur in severe cases, reducing the service life of the rail and accelerating the rate of rail damage. Therefore, it is necessary to accurately control the grinding temperature during rail grinding, and accurately grasp the influence law of rail grinding parameters on the grinding temperature, so as to further improve the grinding quality of rails and extend their service life.  Methods  Based on elastic contact theory and the grinding process of an abrasive belt rail driven by a concave contact wheel, a contact pressure distribution region model of the rail surface is established. According to the principles of grinding heat generation and conduction, a grinding surface temperature distribution model of the abrasive belt rail is established, and the accuracy of the model is verified by simulation analysis. At the same time, the variation rule of grinding temperature under the influence of grinding power, grinding speed and sand belt speed is analyzed, and the distribution of grinding temperature in the rail subsurface is studied.  Results  Firstly, based on the theory of elastic contact and the abrasive belt rail grinding process driven by a concave contact wheel, the actual contact situation between the rail and the abrasive belt is further simplified to make the contact problem more universal and regular. The contact model of rail abrasive belt grinding is solved based on Hertz contact theory, and the distribution shape of the contact area is obtained. And based on the contact model, the maximum stress model of the area is solved, and the relationship between the concentrated grinding positive pressure during the grinding process and the distribution of grinding pressure in the contact area is established, obtaining the grinding pressure distribution model. Secondly, based on the grinding pressure distribution model, the total energy of the grinding area is obtained, and the form of conversion from grinding energy to grinding heat is analyzed. The thermal flow rate in the grinding area is analyzed and integrated, and the discrete point heat source set generated by multi-abrasive grinding is transformed into a continuous surface heat source. The total heat in the grinding zone is calculated based on the grinding power and grinding contact area. The relevant theory of ultimate chip energy is applied to solve the heat flow into the chip. Based on the energy distribution model of a single abrasive grain rubbing on the workpiece surface and the heat distribution ratio between the rail and the belt, the heat flow into the rail is calculated. Based on the transient point heat transfer model in heat conduction theory, the multiple discrete moving point heat source set is transformed into a moving surface heat source model according to the generation and conduction mechanism of grinding heat. The dynamic temperature distribution model and the maximum temperature solution model for the rail grinding surface are constructed. Finally, the simulation model of the temperature field in the grinding area is established based on the heat transfer model of the rail abrasive belt, the grinding pressure distribution model, and the general thermal conductivity differential equation derived from the variational principle of heat transfer and the Gaussian formula. The mathematical model is validated using simulation analysis. At the same time, the influence mechanism of the grinding power, grinding speed, and abrasive belt speed on grinding temperature and the variation law of grinding temperature are analyzed, and the grinding temperature distribution of the rail subsurface is studied.  Conclusions  The highest temperature in the grinding zone is positively correlated with the grinding power and the abrasive belt speed, and negatively correlated with the grinding speed. Moreover, the influence of grinding speed on temperature is the most significant. Therefore, in the process of rail abrasive belt grinding, a higher grinding speed should be used as much as possible to reduce the grinding temperature. At the same time, the increase in abrasive belt speed has a significant effect on temperature rise, so the grinding power should be increased first and then the abrasive belt speed should be increased when the grinding efficiency is increased.



    • FullText(HTML)
  • loading
    • References(19)
  • [1]
    SATOH Y, IWAFUCHI K. Effect of rail grinding on rolling contact fatigue in railway rail used in conventional line in Japan [J]. Wear,2008,265(9/10):1342-1348. doi: 10.1016/j.wear.2008.02.036
    [2]
    金学松, 杜星, 郭俊, 等. 钢轨打磨技术研究进展 [J]. 西南交通大学学报,2010,45(1):1-11. doi: 10.3969/j.issn.0258-2724.2010.01.001

    JIN Xuesong, DU Xing, GUO Jun, et al. State of arts of research on rail grinding [J]. Journal of Southwest Jiaotong University,2010,45(1):1-11. doi: 10.3969/j.issn.0258-2724.2010.01.001
    [3]
    智少丹, 李建勇, 樊文刚, 等. 钢轨打磨接触线模型研究 [J]. 铁道学报,2013,35(10):94-99. doi: 10.3969/j.issn.1001-8360.2013.10.014

    ZHI Shaodan, LI Jianyong, FAN Wengang, et al. Research on contact line model for rail grinding [J]. Journal of the China Railway Society,2013,35(10):94-99. doi: 10.3969/j.issn.1001-8360.2013.10.014
    [4]
    ZHI S D, ZAREMBSKI A M, LI J Y. Towards a better understanding of the rail grinding mechanism [C]//ASME 2013 Rail Transportation Division Fall Technical Conference. October 15-17, 2013. Altoona, Pennsylvania, USA. American Society of Mechanical Engineers, 2013: V001T01A003.
    [5]
    郭战伟. 基于轮轨蠕滑最小化的钢轨打磨研究 [J]. 中国铁道科学,2011,32(6):9-15.

    GUO Zhanwei. Study of rail grinding based on wheel rail creep minimization [J]. China Railway Science,2011,32(6):9-15.
    [6]
    刘月明, 李建勇, 蔡永林, 等. 钢轨打磨技术现状和发展趋势 [J]. 中国铁道科学,2014,35(4):29-37. doi: 10.3969/j.issn.1001-4632.2014.04.05

    LIU Yueming, LI Jianyong, CAI Yonglin, et al. Current state and development trend of rail grinding technology [J]. China Railway Science,2014,35(4):29-37. doi: 10.3969/j.issn.1001-4632.2014.04.05
    [7]
    张子舆. 钢轨打磨过程中钢轨温度场及热机应力研究 [D]. 成都: 西南交通大学, 2017.

    ZHANG Ziyu. Research on temperature field andthermal-mechanical stress of rail in rail grinding process [D]. Chengdu: Southwest Jiaotong University, 2017.
    [8]
    张磊. 单程平面磨削淬硬技术的理论分析和试验研究 [D]. 济南: 山东大学, 2006.

    ZHANG Lei. Study on mechanism and experiment of single-pass surface grind-hardening technology [D]. Jinan: Shandong University, 2006.
    [9]
    LI B Z, ZHU D H, PANG J Z, et al. Quadratic curve heat flux distribution model in the grinding zone [J]. The International Journal of Advanced Manufacturing Technology,2011,54(9):931-940. doi: 10.1007/s00170-010-2990-y
    [10]
    TIAN Y, SHIRINZADEH B, ZHANG D, et al. Effects of the heat source profiles on the thermal distribution for ultraprecision grinding [J]. Precision Engineering,2009,33(4):447-458. doi: 10.1016/j.precisioneng.2008.12.002
    [11]
    SHAH S M, NÉLIAS D, ZAIN-UL-ABDEIN M, et al. Numerical simulation of grinding induced phase transformation and residual stresses in AISI-52100 steel [J]. Finite Elements in Analysis and Design,2012,61:1-11. doi: 10.1016/j.finel.2012.05.010
    [12]
    GUO C, MALKIN S. Inverse heat transfer analysis of grinding, part 1: Methods [J]. Journal of Engineering for Industry,1996,118(1):137-142. doi: 10.1115/1.2803634
    [13]
    ZHANG L C, MAHDI M. Applied mechanics in grinding—IV. The mechanism of grinding induced phase transformation [J]. International Journal of Machine Tools & Manufacture,1995,35(10):1397-1409. doi: 10.1016/0890-6955(95)93590-3
    [14]
    聂蒙, 李建勇, 沈海阔, 等. 钢轨打磨作业过程中磨削温度建模与仿真 [J]. 铁道学报,2013,35(10):89-93. doi: 10.3969/j.issn.1001-8360.2013.10.013

    NIE Meng, LI Jianyong, SHEN Haikuo, et al. Modeling and simulation of temperature in process of rail grinding operation [J]. Journal of the China Railway Society,2013,35(10):89-93. doi: 10.3969/j.issn.1001-8360.2013.10.013
    [15]
    段金良. 钢轨冷却过程中温度场及弯曲变形数值模拟研究[D]. 包头: 内蒙古科技大学, 2012.

    DUAN Jinliang. Numerical simulation of temperature field anddeformation in rail cooling process [D]. Baotou: Inner Mongolia University of Science & Technology, 2012.
    [16]
    杨天勇. 钢轨砂带磨削的残余应力及其影响因素研究 [D]. 北京: 北京交通大学, 2019.

    YANG Tianyong. Research on residual stress state and influence factors of rail grinding with abrasive belt [D]. Beijing: Beijing Jiaotong University, 2019.
    [17]
    GUO C, WU Y, VARGHESE V, et al. Temperatures and energy partition for grinding with vitrified CBN wheels [J]. CIRP Annals-Manufacturing Technology,1999,48(1):247-250. doi: 10.1016/S0007-8506(07)63176-X
    [18]
    ZHOU K, DING H H, STEENBERGEN M, et al. Temperature field and material response as a function of rail grinding parameters [J]. International Journal of Heat and Mass Transfer,2021,175:121366. doi: 10.1016/j.ijheatmasstransfer.2021.12136
    [19]
    刘月明, 何喆, 王荣全, 等. 钢轨试件砂带磨削行为试验研究 [J]. 应用基础与工程科学学报,2017,25(2):419-426. doi: 10.16058/j.issn.1005-0930.2017.02.019

    LIU Yueming, HE Zhe, WANG Rongquan, et al. Experimental investigation on grinding behavior of abrasive belt for rail specimen [J]. Journal of Basic Science and Engineering,2017,25(2):419-426. doi: 10.16058/j.issn.1005-0930.2017.02.019
